PASSION MP 6000H/RP 6000


The GECKO® PASSION 6000 is the world's first hybrid True Diversity wireless microphone system that fuses the best of both analog and digital technologies to deliver the best natural tone of your voice and instruments wirelessly in this modern digital era filled with digital interferences.

The PASSION MP 6000H headband condenser microphone and wireless body-pack transmitter are designed and developed for applications in broadcast studios, theaters, houses-of-worship, corporations, schools, concert halls, and other live performance venues. The PASSION MP 6000H body-pack wireless transmitter features a ¼ Wave Flex Antenna, High-Density ABS Body, Belt-Clip, IR Port, On/Off Switch, Auto-Impedance Matching Mini XLR Input, Volume Control, Battery Compartment, Frequency Setting Buttons, and a Backlit LCD displaying Group, Channel, Frequency, as well as Battery Life. You can also convert your musical instrument into wireless on this system using either the complementary CP 2 Instrument Converter Cable or any other optional supported accessories.

Coupled with C.R.I.S.T.A.L.® Audiophile PreAmps, Advanced Hybrid Signal-Enhancing Filter (AHSEF)™, and Phase-Locked Loop (PLL)™ synthesized technology, the PASSION RP 6000 wireless receiver system is able to send and receive secured audio transmission in great clarity. The PASSION RP 6000 comes ready with a total of 100 UHF Preset Channels over 10 Groups, 4-Step Transmission & Reception Power Level (POL), AF & RF Signal Strength Level Meters, Quiet Power-Up/Shut-Down Design, Infrared (IR) Synchronisation, and Frequency Scan.

The GECKO® PASSION 6000 wireless systems are manufactured-on-demand (MOD).

SPECIFICATION

GECKO® PASSION MP 6000H Headband Condenser Microphone

  • Element: Pre-Polarized Condenser
  • Principle of Operation: Pressure Gradient
  • Polar Pattern: Cardioid
  • Frequency Response: 20Hz ~ 20kHz
  • Sensitivity: 6mV/Pa; -44 dB re. 1V/Pa
  • Output Impedance: ≤100Ω
  • Noise Level: ≤38dB
  • Power Requirements: 1.5V ~ 10V DC
  • Cable Length: 1.25m
  • Output Connector: Mini XLR Female
  • Color: Light Skin Tone

GECKO® PASSION CP 2 Instrument Converter Cable

  • Cable Length: 1m
  • Output Connector: Mini XLR Female
  • Input Connector:  ¼” TS
  • Color: Black

GECKO® PASSION MP 6000H Body-Pack Transmitter

  • Frequency Response: 20Hz ~ 20kHz
  • Frequency Range: UHF: 600 ~ 952MHz (Region Dependent)
  • Preset Channels: UHF: 100
  • Oscillation: Phase-Locked Loop (PLL)™ Synthesized
  • Stability: ±0.005% (-10°C ~ 50°C)
  • AF Input: Mini XLR Male
  • RF Output: 10mW
  • Display: Backlit LCD
  • Interface: Infrared (IR) Synchronisation
  • Power Switch: Digital Relayed ON/OFF
  • Power Requirements: 2 x 1.5V AA Alkaline Batteries (≥1800mAH)
  • Controls: Power ON/OFF, Volume, SET Frequency
  • Operating Time: 10 Hours (Batteries Dependent)

Physical Properties

  • Case Material: High-Density ABS
  • Color: Black
  • Weight: 70g (without Batteries)

  • Dimension: (H) 88mm x (W) 65mm x (D) 25mm;
  • Antenna: ¼ Wave Flex, (L) 82mm

GECKO® PASSION RP 6000 Receiver

  • System: C.R.I.S.T.A.L.® Audiophile PreAmps, Advanced Hybrid Signal-Enhancing Filter (AHSEF)™, Infrared (IR) Synchronisation, Frequency Scan, 4-Step Transmission & Reception Power Level (POL)
  • Frequency Range: UHF: 600 ~ 952MHz (Region Dependent)
  • Preset Channels: 100 (10 Groups x 10 UHF Channels)
  • Oscillation: Phase-Locked Loop (PLL)™ Synthesized
  • Stability: ±0.005% (-10°C ~ 50°C)
  • THD + N: <0.5%, @ 1kHz
  • Frequency Response: 20Hz ~ 20kHz
  • Output Connectors: Balanced XLR Male, ¼” TS, Unbalanced
  • Display: Backlit LCD (63mm*22mm)
  • Power Switch: Digital Relayed ON/OFF
  • Power Requirements: 12~18V DC, 1000mA
  • Antenna Connections: BNC

Physical Properties

  • Case Material: Steel
  • Color: Black
  • Weight: 1.1kg, without Antennas
  • Dimension: (H) 44mm x (W) 210mm x (D) 180mm
  • Antenna: (L) 215mm

Included Accessories

  • UHF Antennas (2)
  • RM-12-1000-X AC/DC Universal Power Adapter
  • 1.5V AA Alkaline Batteries (2)
  • GECKO® PASSION CP 2 Instrument Converter Cable
  • Windscreen
  • GECKO® PASSION Microphone Case
